YT JM Slow Speed Electric Winch for lifting pulling Electric Control Box with Push Button

Name: YT JM Slow Speed Electric Winch for lifting pulling Electric Control Box with Push Button
Brand: Yuantai
Price: 1 USD

Place of Origin : Henan, China (Mainland)

Brand Name : Yuantai

Certification : ISO;CE;SGS

Model Number : JM

Power Source : Electric

Capacity : 2-65t

MOQ : 1

Price : Negotiation

Packaging Details : Fumigation wooden box

Delivery Time : 15days after we got deposit

Payment Terms : TT/LC/Others

Supply Ability : 10000 sets per year

Application : widely

Contact Now

Product Description

SPECLFICATION :

1.Single drum or dual drum.
2.Frequent reversal,high starting torque.
3.Button or cam control
4.Manual lift

YT JM Slow Speed Electric Winch for lifting pulling Electric Control Box with Push Button

With high quality products and good services, we are very popular at home and abroad.

Items	Rated load, KN	Rated speed, m/min	Rope capacity, m	Rope diameter, mm	Motor	Power	Size, mm	Weight, kg
JM1	10	15	100	9.3	Y112M-6	3	620701417	270
JM1.6	16	16	150	12.5	Y132M2-6	5.5	945996570	500
JM2	20	16	150	13	Y160M-6	7.5	945996570	550
JM3.2	32	9.5	150	15.5	YZR160M2-6	7.5	14301160910	1100
JM3.2B	32	12	195	15.5	YZR160M2-6	7.5	10821014610	536
JM5	50	10	270	21.5	YZR160L-6	11	12351230805	1560
JM5B	50	9.5	200	21.5	YZR160L-6	11	16201260945	1800
JM5C	50	9.5	250	21.5	YZR160L-6	11	12351230805	1800
JM5D	50	15	250	21.5	YZR180L-6	15	12351230805	1850
JM5E	50	20	250	21.5	YZR200L-6	22	12351230805	2000
JM6	60	9.5	270	24	YZR180L-6	15	12351230805	1800
JM8	80	8	250	26	YZR180L-6	15	20901475956	2900
JM8B	80	9.5	350	26	YZR180L-6	15	10751598985	2650

Feature of electric anchor winches for boats:

1) Reasonable structure and design hoist
2) Easy to install and Maintenance
3) High efficiency and stable performance
4) Top quality with competitive and economic price
5)Double Speed: Low Speed and Normal Speed

Safty Device of electric anchor winches for boats:

1. Double Limit Switch,
2. Current overload protection function,
3. High quality polyurethane materials buffer.
4. Emergency stop system.
