The large Discount in 2015 Yuantai single Girder electric gantry crane price

Place of Origin : ChinaHenan, China (Mainland)

Brand Name : YAUNTAI

Certification : ISO, CE, SGS,etc

Model Number : MH

Usage : Construction Hoist

Power Source : Electric

Sling Type : Wire Rope

Maximum Lifting Weight : 100kn

Maximum Lifting Height : 9m

Lift Speed : According to u demand

MOQ : 1

Price : negotiation

Packaging Details : Packaged by woven plastic woven cloth.electricals and parts packaged by plywood crate

Delivery Time : Within 30days after receiving the deposit

Payment Terms : TT/LC/Otherts

Supply Ability : 10000 sets per year

Contact Now

Production Description of mini gantry crane price
The large Discount in 2015 Yuantai single Girder electric gantry crane price
  • Designed and made according to JB/T 1306 Electric Double Girder
    Crane
  • The matched hoisting system have MG,MZ,MH,BMG etc according
    to the gantry crane.
  • The light small lifting equipment with running way
  • Hoisting goods in the factory, warehouse, stockyard.etc.
  • Banned to use in some dangerous environment, such as easily
    combustible,explosive,etc
Span S(m) 12 16 20 24
Lifting height m 9 9 9 9
Lifting speed m/min 8 8 8 8
Trolley speed m/min 20 20 20 20
Crane speed m/min 20 20 20 20
Lifting motor kw 4.5 4.5 4.5 4.5
Trolley motor kw 0.4 0.4 0.4 0.4
Total weight kg 8700 9900 12600 14300
Max Wheel Load KN 42 46 50 54
Track P24 P24 P24 P24
Main dimension mm 12 16 20 24
Rail top to main top H 10635 10685 10785 10885
Wheel base W 6000 6000 7000 7000
Crane width B 6400 6400 7500 7500
Hook left limitation S1 850 850 850 850
Hook right limitation S2 1300 1300 1300 1300
Left cantilever L1 3000 4000 5000 6000
Right cantilever L2 3000 4000 5000 6000

Gantry Crane Description:

The large Discount in 2015 Yuantai single Girder electric gantry crane price

The large Discount in 2015 Yuantai single Girder electric gantry crane price

The large Discount in 2015 Yuantai single Girder electric gantry crane price
